Iatrogenic Horner’s syndrome after insertion of a central venous catheter: recommendations for clinical practice
The Egyptian Journal of Internal Medicine volume 34, Article number: 55 (2022)
Horner’s syndrome is a rare complication of central venous catheter (CVC) insertion. It comprises a triad of unilateral ptosis, ipsilateral meiosis with a normally reactive pupil, and ipsilateral facial anhidrosis of variable spread.
A 25-year-old female who underwent CVC insertion developed ptosis, reverse ptosis, meiosis, dilational lag, and enophthalmos after her procedure. The patient was diagnosed with a case of Horner’s syndrome attributed to occulosympathetic damage due to CVC in the catheter, after exclusion of all other sources. The patient was counseled regarding the etiology of the disease and advised monthly follow-up.
Horner’s syndrome is an uncommon complication that can easily be prevented by corrections in technique and experience. The study emphasizes the establishment of diagnostic and preventive principles for HS.
Horner’s syndrome (HS), typically described as a triad of unilateral ptosis, ipsilateral meiosis with a normally reactive pupil, and ipsilateral facial anhidrosis of variable spread, which occurs due to a disruption in the sympathetic supply of the eye . The Swiss ophthalmologist, Johann Friedrich Horner, was the first person to fully describe the condition in humans and attribute it to oculosympathetic paresis .
Catheterization by the central venous catheter (CVC) is a common procedure typically done with a Swan-Ganz catheter, mostly inserted into the internal jugular vein to assist in intravascular resuscitation. HS is one of the rarest complications of CVC insertion . Here, we present a case of possible iatrogenic injury due to CVC insertion, leading to oculosympathetic palsy or HS. To our knowledge, this is the first case report of iatrogenic HS outlining recommendations to reduce the incidence of this complication.
A 25-year-old primiparous woman was admitted to the high dependency unit (HDU) after a lower segment cesarian section (LSCS) under spinal anesthesia at 36 gestational weeks. Per-operatively, the patient had an uncontrolled post-partum hemorrhage, ultimately requiring a partial hysterectomy. As a preparatory measure for her surgery and anticipated post-partum hemorrhage, an intensivist inserted a single-lumen CVC (7 Fr x 20cm) in the patient’s right internal jugular vein (IJV) under ultrasound guidance.
On her first post-operative day, the patient noticed that her right upper eyelid is drooped and her right eye appeared smaller than the left one. Owing to this, neurology and ophthalmology consults were made.
On examination, her unaided visual acuity was 6/6 bilaterally. She had right-sided enophthalmos of 3 mm on Hertle’s exophthalmometer, right-sided blepharoptosis, and reverse ptosis (MRD1 = 3 mm, MRD2 = 2.5 mm), a PFH of 5.5 mm and a mild right-sided periocular swelling, as seen in Fig. 1. In the left eye, the PFH was 7.5 mm, MRD1 was 4 mm and MRD2 was 3.5 mm. Pupillary examination revealed anisocoria in room light (OD: 2 mm, OS: 3 mm) which increased in the dark room (OD: 3mm, OS: 4.5 mm). On direct light reflex, there was a dilation lag in the right eye; however, there was no relative afferent pupillary defect (RAPD). The Hirschberg corneal reflex test was bilaterally central. The cover-uncover test showed bilateral esophoria. Her extra-ocular movements were within her full range of motion bilaterally, and she had no diplopia in any of the gazes. The rest of her anterior and posterior segment examinations were unremarkable. The general physical examination revealed a central venous line in the right internal jugular vein and associated neck swelling at the insertion site. No other neurological deficit including abnormal eye movements, ipsilateral limb ataxia, or dissociated sensory loss was noted.
The MRI of the brain and cervical spine came out to be unremarkable in establishing any pathology. A diagnosis of HS due to the central venous line was based on the exclusion of other pathologies. The patient was counseled regarding the etiology and possible course of the disease. She was advised to come for a monthly follow-up at our neuro-ophthalmology clinic.
CVC insertion is performed on millions of patients per day with well-documented complications [1, 3]. The incidence of HS due to CVC is reported to be 2% by Butty et al. in his prospective study . Any disruption within the oculosympathetic tract causes HS, which may occur within the first-order (central), second-order (preganglionic), or third-order (postganglionic) neurons as seen in Fig. 2 .
The sympathetic first-order neurons originate in the posterolateral hypothalamus and run through the lateral brainstem and into the intermediolateral gray column of the spinal cord at C8-T1, where they are part of the ciliospinal center of Budge. The second-order neurons pass across the pulmonary apex into the cervical sympathetic chain in the carotid sheath. The third-order neurons originate in the superior cervical (stellate) ganglion from where they travel up the adventitia of the internal carotid artery into the cranium. Here, the fibers divide into long and short ciliary nerves to reach the target tissues .
There are multiple causes of HS divided into those affecting first-order neurons (central tumors, strokes, demyelinating disorders, syringomyelia, neck trauma, etc.), second-order neurons (Pancoast tumor, schwannomas, trauma, etc.), and third-order neurons (trauma, tumors, infection, cluster headaches, etc.) . They are enlisted in detail in Table 1. Maloney et al. reported that in about 450 patients with HS, only about 65% (270 individuals) had an identifiable etiology, of which 13% were central, 44% preganglionic, and 43% postganglionic .
The right IJV is the preferred side for CVC insertion because it has predictable anatomy, a high success rate, and a low risk of complications . These complications include carotid artery aneurysm (most common), aortic dissection, thrombosis, arteriovenous fistula formation, pneumothorax, and HS . Ways in which a CVC may cause HS include direct damage to the sympathetic chain, direct damage to the peri-subclavian neural loops, and hematoma of associated vasculature (especially if the hematoma is trapped within the carotid sheath) [3,4,5,6].
Clinical features of HS include ptosis (with or without reverse ptosis) and meiosis (more apparent in darkness), which occur due to paresis of muller and dilator pupillae muscles, respectively. In addition, anhidrosis may occur due to the involvement of sympathetic innervation of facial sweat glands . Features in addition to these may be seen with respect to the underlying cause as seen in Table 1. Diagnosis of HS is made by pharmacological tests including 5% cocaine (normal pupil dilates, Horner pupil unresponsive), 0.5% Apraclonidine (normal pupil minimally constricts, Horner pupil dilates), 0.5% hydroxyamphetamine (normal pupil dilates, postganglionic Horner pupil unresponsive), and 1% phenylephrine or 2% epinephrine (normal pupil unresponsive, postganglionic Horner pupil dilates) [4, 7].
Once a diagnosis of HS is considered probable, depending on the clinical features, a multitude of tests may be carried out, including but not limited to, X-ray cervical spine, MRI of the brain, CT scan of the chest, and/or CT/MRI angiography, to identify the underlying pathology [1, 8].
Here, we enlist the following recommendations to reduce the likelihood of developing HS after CVC:
A CVC should be inserted under the guidance of direct ultrasound, as it has been shown to reduce the likelihood of developing HS. The cervical sympathetic chain itself can be identified via ultrasound . The chain may be identified lying medial to the scalene muscles; lateral to the longus colli, esophagus, and trachea; superior to the subclavian artery; and posterior to the pleura and vertebral vessels .
Avoid keeping the needle angle too steep; otherwise, the needle may pass behind the carotid artery to damage the sympathetic chain .
Once the head is tilted to the left by more than 40o, the risk of IJV overlapping the carotid artery is increased significantly, leading to greater chances of developing HS. Tilting the head within 30o and keeping the neck muscles relaxed leads to higher success rates and minimizes the patient’s discomfort .
Testing for HS can be positive with apraclonidine as soon as 3 h after the insult. Pharmacological testing should be done as soon as possible and once HS is diagnosed and attributed to catheter insertion; the CVC should be removed by a specialist to limit further damage .
Posterior approach to IJV underneath the sternocleidomastoid muscle should be avoided as the likelihood of damaging the sympathetic chain increases with this approach. An anterior approach is recommended for the ease of procedure, limited complication rate, and an overall better outcome .
Conclusively, Horner syndrome is an uncommon complication of a common procedure, CVC insertion, that can easily be prevented with experience and correction in technique. The study also emphasizes the establishment of diagnostic and preventive principles for HS.
Availability of data and materials
The dataset generated or analyzed during the current study is not publicly available due to patient confidentiality but is available from the corresponding author on reasonable request.
Central venous catheter
Lower segment cesarian section
Internal jugular vein
Marginal-reflex distance at 1mm
Marginal-reflex distance at 2mm
Palpaberal fissure height
Magnetic resonance imaging
Kanagalingam S, Miller NR (2015) Horner syndrome: clinical perspectives. Eye and brain. 7:35. https://doi.org/10.2147/EB.S63633
Horner F (1968) On a form of ptosis. Arch Neurol 19(5):541–542. https://doi.org/10.1001/archneur.1968.00480050111013
Butty Z, Gopwani J, Mehta S, Margolin E (2016) Horner’s syndrome in patients admitted to the intensive care unit that have undergone central venous catheterization: a prospective study. Eye 30(1):31–33. https://doi.org/10.1038/eye.2015.181
Maloney WF, Younge BR, Moyer NJ (1980) Evaluation of the causes and accuracy of pharmacologic localization in Horner’s syndrome. Am J Ophthalmol 90(3):394–402. https://doi.org/10.1016/S0002-9394(14)74924-4
Ateş Ö, Koçyiğit İ, Cilan H, Oğuzhan N, Tokgöz B, Oymak O (2013) Horner syndrome following ınternal jugular vein catheter ınsertion: report of two cases. Türk Nefroloji Diyaliz ve Transplantasyon Dergisi. 22(2):218–220. https://doi.org/10.5262/tndt.2013.1002.16
Vinod KV, Sivabal V, Vidya MV (2017) Iatrogenic Horner's syndrome: a cause for diagnostic confusion in the emergency department. World J Emerg Med 8(3):235. https://doi.org/10.5847/wjem.j.1920-8642.2017.03.014
Mughal M, Longmuir R (2009) Current pharmacologic testing for Horner syndrome. Curr Neurol Neurosci Rep 9(5):384–389. https://doi.org/10.1007/s11910-009-0056-z
Almog Y, Gepstein R, Kesler A (2010) Diagnostic value of imaging in horner syndrome in adults. J Neuro-Ophthalmol 30(1):7–11. https://doi.org/10.1097/WNO.0b013e3181ce1a12
Narouze S, Vydyanathan A, Patel N (2007) Ultrasound-guided stellate ganglion block successfully prevented esophageal puncture. Pain Physician 10(6):747. https://doi.org/10.36076/ppj.2007/10/747
None to declare.
None to declare.
Ethics approval and consent to participate
An informed written consent to participate in the study was taken from the parents of the patient who are his legal guardians. Confidentiality was maintained at all levels of the study. Ethical approval was also obtained from the Hospital Ethics Review Committee.
Consent for publication
An informed written consent for publication was taken from the parents of the patient who are his legal guardians.
The authors declare that they have no competing interests.
